PHANTOM® P-150

STABLE, HIGHLY MANEUVERABLE CONFINED SPACES PLATFORM FOR PWR OUTAGE SUPPORT AND VISUAL EXAMS

The Phantom® P-150 is a portable system designed for PWR visual exams of staged reactor equipment, NDT support, FME identification/retrieval and many other outage exams (please see Applications, below). Analog ROV configuration permits easy fault detection and plug/play integration of accessories. The Phantom® P-150 is ideally designed for the nuclear industry with stable materials and FME concerns as a top priority.

Case Studies

PHANTOM® P-150 TECHNOLOGY


The Phantom® P-150 operates with the NIS-300 Control System; A portable system designed to be backwards compatible with existing P-150 ROVs and allow plug and play configurations for both radiation tolerant and HD 1080P video options. NIS-300 also supports unique thruster configurations and cable lengths up to 500 feet.

Phantom P150 ROV

Aluminum Chassis

Hard annodized aluminum chassis.

Safety Tied Hardware

Camera Tilt

Tilting + / - 90 degrees

LED Lights

LED Lights - 2 standard, 4 optional

  • Salient Features
  • PWR and Potable Water Applications
  • Thrusters
  • Weight & Size
  • Specifications

Salient Features

  •  Portable system, adept at weld visual exams/ NDT support and small-object-retrieval
  •  The P-150 open design allows easy integration of additional sensors and cameras
  •  Two horizontal and two “vertrans” thrusters
  •  No electronics in the sub unit ensures reliability in areas of high radiation
  •  Hardwired for fast and easy integration with accessories and easy fault-detection
  •  3 coax umbilical: l permits HD 1080 video imagery or 2 continuous cameras operation
  •  4 x 160 Watt LED lighting option available on the 2 lighting circuits
  •  Plug and play radiation tolerant camera options

PWR and Potable Water Applications

  •  Upper and Lower Internals, lifts and visual examination
  •  RWST visuals
  •  Small object identification and retrieval
  •  Support of Tri-nuke vacuuming operations, both flange and vessel floor
  •  Vessel inlet and outlet visual exams
  •  Vessel Flange pre/post cleaning visual examination
  •  The most stable video platform of its size
  •  Designed for nuclear industry with stable materials and FME concerns as a priority
  •  Potable water tanks, both elevated and in ground, with umbilical lengths to 500’

Thrusters

  •  48 volts DC motors, driven at around 60VDC
  •  Individually controlled
  •  Mineral oil filled compensator on shaft seal

Weight & Size

  Weight: :  18 kg (40 lbs)
  Length :  64.25cm (25.30 in)
  Width :  35.24cm (13.875 in)
  Height :  29.21cm (11.5 in)
